Double Wing House Expandable Prefab Container Solution
Feature of the double wing house:
Quick Assembly and Disassembly: The Double Wing House can be set up or taken down swiftly, making it ideal for rapidly changing circumstances or emergency situations.
Spacious and Customizable Design: This expandable prefab container house offers a larger living space than standard containers, with the option to modify the layout to suit specific needs.
Portable and Easy to Relocate: As a foldable house Australia solution, the Double Wing House can be easily transported and relocated, ensuring flexibility in living arrangements.
Durability and Weather Resistance: Built with high-quality materials, these prefab expandable containers are designed to withstand harsh weather conditions, providing long-lasting comfort and safety.
Energy Efficient and Eco-friendly: Custom prefab homes like the Double Wing House are built with sustainable materials, helping reduce energy consumption and environmental impact.
Cost-effective: This solution is more affordable than traditional housing, offering a budget-friendly option for those seeking modern, customizable living spaces.
☞☞☞Click this link to view more videos from CBOX’s YouTube!
Material List
| Steel Structure | List | Part Name | Specification |
| 1 | Steel column | Steel panel 3mm thickness bend part | |
| 2 | Main bottom beam | 150*75*3.0mm | |
| 3 | Main top beam | 12#*6mm | |
| 4 | Secondary beam | 80*80*2.0mm | |
| 5 | Panel | Galvanized steel corrugated sheet 1.0mm | |
| 6 | Bottom frame purlin | 80*40*2.0mm | |
| Panel, Door, and Window | 7 | Ceiling | 1150*50*0.326mm double-side Choi foam sandwich panel |
| (White and grey) | |||
| 8 | External wall panel | Bending piping 2.5mm+1150*50*0.326mm 0.326mm double side Choi foam sandwich panel | |
| (White and grey) | |||
| 9 | Floor | Fireproof panel 15mm (yellow) +PVC grain board | |
| 10 | Door panel | 304 SS door (primary colors)
W*H: 1520mm*2200mm, 1 set |
|
| 11 | Sliding window | Aluminum alloy sliding window (white)
W*H: 930mm*1200mm, 8 sets |
About CBOX
32,000 m PRODUCTION BASE & OVER 1200 STAFFS
We are the first and only prefab house supplier using a fully automatic production line in China
Guangdong Cbox Co., Ltd, which covers 350,000 square meters and has an annual output of 200,000 containers (500+ sets per day), focuses on designing and developing, producing, selling, installing, operating, and serving as a whole, providing one-stop box rental and manufacturing for customers.
After 17 years of hard work by the company’s core team, it has obtained 46 invention patents and utility model patents. The workshop is equipped with automated robotic arms to reduce labor costs and reduce costs for customers.
Guangdong Cbox Co., Limited has 29 factories, and the product categories produced include flat-pack container houses, detachable container houses, detachable flat pack container houses, foldable container houses, slide folding container houses, portable toilets, etc.
We take the need of a customer as the base, green safe, economical, and comfortable living experience as the root and development of the industry as the purpose.
With the support of automatic manipulators and excellent sales engineers, CBOX is confident that we can meet the requirements of customers on quality, quantity, and even technical guidance.
Comfortable and Stylish
