Container Home Designs – Foldable and Portable
Feature of slide folding container
Quick Assembly and Disassembly: The quick build container house can be set up or taken down swiftly, making it suitable for rapidly changing circumstances or emergency situations.
Space-Saving and Portable: This foldable house is compact and portable, making transportation and storage convenient for both residential and commercial uses.
Durable and Modern Design: The container home design features high-quality materials and a contemporary look, ensuring reliability and aesthetic appeal.
Cost-Effective and Efficient: The flat pack folding container house offers a budget-friendly option without compromising quality, ideal for modular housing needs.
Versatile Applications: Perfect for modular temporary housing, it suits various uses like disaster relief, worker accommodation, or mobile offices.
CBOX container home designs offer foldable, portable, and quick-build solutions, ideal for modern and efficient modular temporary housing. Featuring durable materials and a sleek look, these flat pack folding container houses are cost-effective, versatile, and easy to assemble, making them the perfect choice for a quick build container house that adapts to your needs.
☛☛☛For more videos about portable cabins please click this link to CBOX’s Youtube
Material List
| Product Specifications | Folded Height | H=440mm 40HQ can load 10 sets |
| L*W*H(mm) | 5830mm*2500mm*2470mm Inner size: 5650mm*2320mm*2200mm |
|
| Roof Form | Flat Roof | |
| Number Of Layers | ≤2 layers | |
| Structure | Column | Specification 50mm*160mm Roller Beam Material Thickness 2.3mm Material Q235B |
| Roof Main Beam | Specification 50*160mm Roller Beam Material Thickness 2.3mm Material=Q235B |
|
| Roof Secondary Beam | Galvanized Cold Rolled Section Steel C Type Material Thickness=1.0mm 6 Pieces Material Q235B |
|
| Ground Main Beam | Height 50*140mm Roller Beam Material Thickness 2.3mm Material=Q235B |
|
| Ground Secondary Beam | Galvanized Cold Rolled Section Steel C Type Material Thickness 1.5mm 9 Pieces Material=Q235B |
|
| Bolt | 8.8 Class High-Strength Bolts, 6 | |
| Paint | Electrostatic spraying plastic powder baking varnish ≥80μm | |
| Roof | Roof Panel | EPS Color Steel Sandwich Panel Thickness=50mm Color White-Gray Free fall |
| Ground | Substrate | 18mm Fireproof Glass Magnesium Board |
| Wall | Insulation Cotton | 50mm Thickness Color Steel EPS Sandwich Panel Class B Fireproof |
| Color steel Plate | Panel Coler Streel Plate Thickness 0.4mm | |
| Door | Specification | Width×mm*1900mm |
| Material | Steel Door Concealed Lock |
|
| Window | Specification | 950mm*1100mm |
| Frame Material | Plastic Steel | |
| Glass | Single Layer Glass |
About us
——Guangdong Cbox Co., Limited——
Guangdong Cbox Co., Limited. which covers 350,000 square meters and has an annual output of 200,000 containers, focusing on designing and developing, producing, selling, installing, operating, and serving as a whole, providing one-stop box rental and manufacturing for customers.
C.Box covers a series of products such as steel structure workshops, flat pack container houses, modified shipping container houses, detachable container houses, folding container houses, expandable container houses, slide folding container houses, portable toilets, portable ion, installation, Services, and other one-stop solutions.
After 15 years of hard work by the company’s core team, it has obtained 46 invention patents and utility model patents.
We take the needs of customers as the base, green safe, economical, and comfortable living experience as the root and development of the industry as the purpose.
Comfortable and Stylish
