Portable Fold Out Container House Nansha by CBOX Container House
Product details of the portable fold out container house
Quick Overview
CBOX Container House portable fold out container house is manufactured utilizing premium materials sourced from the certified vendors. To ensure product quality, the product is produced under the supervision of our experienced quality assurance team. The market share of the product is getting increasingly larger, showing its wide market application.
Product Information
To better learn about portable fold out container house, CBOX Container House will provide detailed pictures and detailed information in the following section for your reference.
About Us
Guangdong Cbox Co., Limited. which covers 350,000 square meters and has an annual output of 200,000 containers, focusing on designing and developing, producing, selling, installing, operating, and serving as a whole, providing one-stop box rental and manufacturing for customers.
C.Box covers a series of products such as steel structure workshops, flat pack container house, modified shipping container house, detachable container house, folding container house, expandable container house, portable ion, installation, Services, and other one-stop solutions.
After 15 years of hard work by the company's core team, it has obtained 46 invention patents and utility model patents.
We take the need of customers as the base, green safe, economical, and comfortable living experience as the root and development of the industry as the purpose.
Product Specifications
|
Product Specifications |
Folded Height |
H=440mm 40HQ can load 10 sets |
|
L*W*H(mm) |
5830mm*2500mm*2470mm Inner size: 5650mm*2320mm*2200mm |
|
|
Roof Form |
Flat Roof |
|
|
Number Of Layers |
≤2 layers |
|
|
Structure |
Column |
Specification 50mm*160mm Roller Beam Material Thickness 2.3mm Material Q235B |
|
Roof Main Beam |
Specification 50*160mm Roller Beam Material Thickness 2.3mm Material=Q235B |
|
|
Roof Secondary Beam |
Galvanized Cold Rolled Section Steel C Type Material Thickness=1.0mm 6 Pices Material Q235B |
|
|
Ground Main Beam |
Height 50*140mm Roller Beam Material Thickness 2.3mm Material=Q235B |
|
|
Ground Secondary Beam |
Galvanized Cold Rolled Section Steel C Type Material Thickness 1.5mm 9 Pices Material=Q235B |
|
|
Bolt |
8.8 Class High-Strength Bolts, 6 |
|
|
Paint |
Electrostatic spraying plastic powder baking varnish ≥80μm |
|
|
Roof |
Roof Panel |
EPS Color Steel Sandwich Panel Thickness=50mm Color White-Gray Free fall |
|
Ground |
Substrate |
18mm Fireproof Glass Magnesium Board |
|
Wall |
Insulation Cotton |
50mm Thickness Color Steel EPS Sandwich Panel Class B Fireproof |
|
Color steel Plate |
Panel Coler Streel Plate Thickness 0.4mm |
|
|
Door |
Specification |
Width×Height=840mm*1900mm |
|
Material |
Steel Door Concealed Lock |
|
|
Window |
Specification |
950mm*1100mm |
|
Fram Material |
Plastic Steel |
|
|
Glass |
Single Layer Glass |
Affordable folding prefab modular homes offer the ultimate blend of convenience and creativity. These portable container houses are engineered for rapid deployment in any location—whether as a countryside retreat, urban workspace, or emergency shelter. Choose from endless customizable container home designs to perfectly adapt layouts, aesthetics, and functionality to your needs. Built as modular container homes, they allow effortless expansion or reconfiguration over time. Combining the cost-efficiency of prefab container homes with innovative folding technology, this solution delivers durable, adaptable living without compromising style or budget.
Feature of Fold Out Geothermal Flat Pack House
Cost-effective & rapid construction: Affordable folding container homes slash build costs by up to 50% vs. traditional methods, with prefab container homes factory-built for quick, waste-free assembly in days, not months.
Portability & durability: Relocate portable container houses seamlessly—from rugged terrains to urban hubs—thanks to corrosion-resistant steel frames and compact folding designs that withstand harsh weather.
Customizable living spaces: Transform modular container homes into studios, guesthouses, or multi-level residences using customizable container home designs (e.g., fold-out decks, partition walls, solar-ready roofs).
Scalable modular design: Start small and expand effortlessly—add units vertically or horizontally to modular container homes as your space or budget grows, ensuring long-term adaptability.
other Details
Company Advantages
Guangdong Cbox Co., Limited(CBOX Container House), located in is a comprehensive company. We have a wide range of business including production, processing and sales. And Container house/Prefab house/Portable toilet,Detachable Flat Pack Container House/Detachable Container House/Flat Pack Container House/Folding Co are key products. CBOX Container House regards 'pragmatism, dedication, innovation' as our spirit and we operate our business based on the philosophy of 'integrity cooperation, mutual benefit'. We are committed to providing new and old customers with better products and more professional services. CBOX Container House has built a professional management team to provide a strong guarantee for opening up the market. CBOX Container House is dedicated to providing professional, efficient and economical solutions for customers, so as to meet customers' needs to the greatest extent.
We have ample inventory and discounts for large purchases. Welcome to contact us!
