Note:All our products can be customized, if you need better configuration or other special requirements, please consult our staff.
Steel: Q235B Stainless Steel, 2.3mm
Q235B has a certain elongation, strength, good toughness, and castability, is easy to punch and weld, and is widely used in the manufacture of general mechanical parts. It is mainly used for welded structural parts with high-quality requirements in construction and bridge engineering.
| 1. Bottom frame feet | 2. Bottom frame secondary beam (C-shaped steel) | 3. Bottom frame long side beam (5635mm) |
| 4. Cement fiber board (19mm) | 5. 2mm PVC Carpet | 6. Column trim (2600mm) |
| 7. Prism (2535mm) | 8. Plastic steel windows + anti-theft net | 9. Ceiling plate V-830 profiled steel plate |
| 10. Class A fireproof glass wool | 11. Skin panel (0.45mm) | 12. Top frame secondary beam |
| 13. Top frame long side beam (5635mm) | 14. Top frame feet | 15. Top frame short side beam (2690mm) |
| 16. Top tie beam square tube | 17. Top frame long side beam (5635mm) | 18. Prism (2535mm) |
| 19. Drain pipe | 20. Wall panel (75mm) | 21. PVC baseboard |
| 22. Bottom tie beam square tube | 23. Bottom frame short side (2690mm) |
Anti-rust: Spray Paint（110μ/㎡） + Galvanized
The anti-corrosion treatment of many products of the same type is only made of spray paint, and the density is only 80μ/㎡, which may rust in 2-3 years, resulting in a significant reduction in service life.
But we galvanize first, and then spray 110μ/㎡ anti-rust paint, which can usually reach 10 years of anti-rust time. Greatly provides longevity.
Wall + Floor：Choose high-quality fire and moisture-proof materials
Wall panel: rock wool/glass wool color steel plate.Fire rating: Class A; Moisture-proof rating: Class A
Floor: PVC+glass magnesium board or PVC+cement.It has very good hardness, and it is also a fireproof and moisture-proof material.
Window and Door: Steel Doors + Aluminium Alloy Window
Steel Doors：Use high-quality stainless steel doors, 10 years without rust.
Aluminium Alloy Window：Durable, no rust, easy to install.
We have different configuration options, please contact our sales for details.
Layout:
1. General layout: the empty box with two windows, and one door.
2. Free layout: change according to customer requirements (design drawings are made according to the type and quantity of personnel).
Highlights:
- 200mm large size corner fitting.
- Cement fiberboard + PVC floor covering.
- The circuit can be pre-installed.
- Whole set package.
- The package has wheels for easy movement
Install Service
If you need to assemble the house urgently, we can provide installation service, we will arrange professional personnel from our factory to work at the address you require.
Of course, this will incur additional costs, please contact our staff for details.
Prefabrication production
We Guangdong Cbox has an automated production line composed of automated production machines, which can complete the delivery in a short time.
Comfortable and Stylish
