Foldable Container Home for Earthquake Relief Housing
Foldable Container Home for Earthquake Relief Housing—collapsible steel frame cuts transport volume by 60%, deploys in 2 hours with ISO-certified seismic resistance.
Only 3 minutes
1. Can be transport overall, thus can be recycled to service different projects without reconstruction.
2. Environment protection: no construction waste, materials can be recycled.
3. Nice capacity of water proof, moisture proof and heat insulation and sound insulation.
4. Diversified Specification: Our design can be customized. The doors, windows and front and back walls can be exchanged each other. And the partition walls according to the customers’ requirements.
5. Practical,good space utilization and high performance.
Product Specification
|
Size |
5800*2500*2450mm |
Steel Structure |
Square tube and bending steel plate |
|
Length |
Inner length /external length: 5.80m/5.90m |
Width |
Inner width /external width: 2.3m/2.50m |
|
Height |
Inner height/external height: 2,41m/2.59m |
Wall Panel |
50mm EPS sandwich panel /rock wool sandwich panel ,0.326/0.376/0.426/0.476mm steel sheet |
|
Wall Color |
White color and optional colors |
Color |
White/Grey/Blue colofr for steel frame |
|
Roof |
50mm EPS sandwich panel /rock wool sandwich panel ,0.326/0.376/0.426/0.476mm steel sheet |
Door |
50mm EPS sandwich panel /rock wool sandwich panel ,0.326/0.376/0.426/0.476mm steel sheet with lock /optional doors |
|
Window |
Aluminum sliding openings, PVC sliding openings with security bar |
Floor |
16mm thinkness fire protection MGO board /optional floor |
|
Decoration Wall |
Optional: PVC cladding ,WPC cladding |
Electricity |
Standard (Lighting + socket + switch) |
|
Install Time |
2 Workers 10 mins |
Wind Resistance |
Wind speed≤120 km/h |
|
Earthquake Resistance |
Grade 8 |
Snow Load Capacity Of Roofing |
0.6kn/m2 |
|
Live Load Capacity Of Roofing |
0.6kn/m2 |
Wall Permitted Loading |
0.6kn/m2 |
|
Heat Conductivity Coefficient |
0.35kcal/m2hc |
Delivery Time |
About 15-20 working days |
|
Container Loading |
10 - 12 sets/40HQ |
|
|
Engineered for crisis response, our Foldable Container Home revolutionizes earthquake relief housing. The patented collapsible design transforms into a stormproof shelter within 2 hours – 75% faster than conventional units. Each quick build folding house features galvanized steel walls with 8.0-magnitude seismic resistance, while foldable partitions allow flexible space reconfiguration. Ideal for governments and NGOs, these temporary housing containers ship flat to save 60% transport space, with modular bathrooms pre-wired for rapid field deployment. From disaster resettlement housing to long-term refugee camps, our solution balances urgency with dignity.
ADVANTAGE OF FOLDABLE CONTAINER HOUSE
Space-Saving Transport – Collapsible steel frames reduce logistics costs by 60%, enabling bulk delivery to remote disaster zones.
Rapid Deployment – Quick build folding house system achieves 2-hour assembly with tool-free locking mechanisms.
Multi-Hazard Resistance – ISO-certified seismic/stormproof structure ensures safety in disaster resettlement housing scenarios.
Sanitation Ready – Pre-installed plumbing interfaces for immediate use as temporary housing containers with bathroom units.
advantage
other Details
FAQ
